Drum Asphalt Mix Plant

Capacity: 80t/h ~160t/hContinuous Production

ALT80-160 Series: High-output & Stable Performance Drum Plants

Continuous Production – Uninterrupted Asphalt SupplyThe ALT80-160 Series drum mixing plant operates with a continuous production process, ensuring a steady and consistent asphalt output, ideal for projects requiring high efficiency and minimal downtime.
Energy Efficiency – Optimized Fuel ConsumptionDesigned with advanced heating technology, the ALT80 maximizes fuel efficiency, reducing operational costs while maintaining optimal asphalt quality, making it an eco-friendly and cost-effective solution.
Compact & Stationary Design – Perfect for Medium and Small Projects As a non-mobile asphalt mixing plant, the ALT80-160 Series is the ideal choice for medium and small-scale projects, offering reliable performance without the need for frequent relocation.

1234/4

Highlights

Cold Aggregate Bin

– 4–6 bins (6.5m³ each for ALT100) + load sensors
– Precision volume control; handles diverse aggregate blends for mix recipes.

Drying Drum

– Larger drum (Ø2.2m+ for ALT100) + heat recirculation
– 15% lower fuel use via exhaust heat reuse; handles 160 t/h throughput.

Vibrating Screen

– Not applicable – Continuous mixing bypasses screening.
– Zero screening downtime; ideal for uniform aggregate feeds.

Hot Aggregate Bin

– Storage Silo (7–9t capacity for ALT100)
– Buffer storage ensures uninterrupted truck loading; insulated to retain heat.

Dust Filter

– High-efficiency baghouse (standard for ALT80+)
– Captures 99% of particulates; meets urban emission regulations.

Cold Aggregate Bin

Drying Drum

Vibrating Screen

Hot Aggregate Bin

Dust Filter

Technical specifications

Model	ALT 80	ALT 100	ALT 120
Output	80 t/h	100 t/h	120t/h
Power	135kw	170kw	200 kw
Cold Aggregate Feeding System	6.5m3 X 4	6.5m3 X 4	6.5m3 X 4
Finished Asphalt Storage Bin	5m3	7m3	7m3
Asphalt Temperature	120-180℃
Fuel Consumption	13-15kg/t
Asphalt Tank	30t	35t	35t
Option	bag dust collector/ water dust collector
